Accessories
Cable Rolling Hand
Kurabotte-R series
Positioning adjustment for crimp terminals using robot hands
Equipped with a mechanism to adjust hand orientation, allowing the grasped object to be rolled at any angle
- Model
- Kurabotte-R200
- Purpose
- Angular positioning of crimp terminals and connectors
- Structure
- Parallel grip + sliding
- Stroke
- 15 mm
- Gripping wire diameter
- 1.0 ~ 2.0 mm
Cable Bundle Supply Unit
Kurabotte-P series
Pick up one cable from the cable bundle
It is designed to automate the cable supply process by picking one cable from a bundle.
- Model
- Kurabotte-P200
- Purpose
- Pick up one cable from cable bundle supply
- Structure
- Dedicated structure + grip confirmation sensor
- Gripping wire diameter
- 1.0 ~ 2.0 mm
PCB Assembly Hand
Kurabotte -I series
Hand specialized for gripping connectors and flat cables.
This hand used Kurabotte series. Optimized for gripping board-to-board connectors and flat cables (FFC/FPC), ensuring reliable gripping and fastening.
- Format
- Kurabotte-I200B
- Kurabotte-I200F
- Object
- Board to board connector
- Flat cable (FFC/FPC)
- Structure
- Dedicated structure
- Grip size
- 9.0 x 3.0 ~
18.0 x 5.0 mm - 10.0 ~ 20.0 mm
